Marshall Electronics Input Module for AR-DM2-L Audio Monitor - ARDMAESBNC
What our Experts Think
-
Professional Dual HD‑SDI Inputs – Adds two HD‑SDI input channels to compatible MD‑series rack monitors for versatile source connectivity. Supports standard high‑definition feeds used in broadcast and pro video workflows.
-
Loop‑Through Output – Includes a loop‑through output so you can daisy‑chain the SDI signal to another display or recorder without signal loss.
-
Modular & Swappable – Designed to fit the ’B’‑type expansion slot on Marshall MD series monitors, making upgrades simple and adaptable to changing production needs.
-
Compatible with MD434 & VMD503 – Works seamlessly with popular modular rack monitors to expand input options in studios, OB vans, and AV setups.
-
Durable & Reliable – Built for continuous, professional use with trusted Marshall Electronics quality and backed by a manufacturer warranty.
-
Expert‑Recommended – Ideal for multi‑camera environments and professional video monitoring where flexible SDI input options are essential.
Q&A
Q: What is this module for?
A: An input expansion module that adds digital audio capability to the Marshall AR‑DM2‑L Digital Audio Monitor mainframe.
Q: What type of audio inputs does it provide?
A: It offers 4 unbalanced AES/EBU digital audio inputs on BNC connectors for professional multi‑channel digital sources.
Q: Are outputs included?
A: Yes — 4 passive loop‑through outputs let you pass signals to other equipment without conversion.
Q: How many channels can it support?
A: Supports up to 4‑channel stereo or Dolby multi‑channel decoding when paired with the monitor.
Q: Which device does it work with?
A: Designed specifically for the AR‑DM2‑L 16‑Channel Digital Audio Monitor by Marshall Electronics.
Maintenance Tips
-
Keep BNC & Audio Connectors Clean – Use compressed air or a soft brush to prevent dust buildup.
-
Avoid Cable Strain – Handle audio and BNC cables gently; avoid sharp bends or tension.
-
Ensure Secure Installation – Confirm the module is firmly seated in the AR-DM2-L monitor slot.
-
Use Quality Cables – Certified audio and BNC cables maintain optimal signal quality.
-
Power Off Before Handling – Prevent electrical damage when installing or removing the module.
-
Inspect Regularly – Check connectors and module for wear or loose connections.
-
Protect from Dust & Moisture – Store in a dry, clean environment when not in use.
-
Test Signal Integrity – Periodically verify proper audio and video signal transfer.
