Marshall Electronics TeleCube Fiber Optic Input / Output Base Module - MDTCB
The Marshall MD-TC-B TeleCube Fiber Optic I/O Base Module is used to transmit and receive audio and video signals and is used with MD series rack mount monitors. Using fiber optic technology for transfer of signals, the transmitter is compatible with SMPTE 310M, 292M, 259M, 297M, and 424M transmission standards.
Along with support for embedded audio, the MD-TC-B TeleCube transmits data with a transfer bandwidth ranging from 19.4Mbps to 3Gbps. Transferring data with return loses less than 10db 3 GHz, the transceiver transfers error-free data with very low system jitter. The module provides you with the option of CWDM laser diodes for transmission and supports long distance transmissions
Features
- Audio / Video Transceiver
- For MD Series Rack Mount Monitors
- Uses Fiber Optic Cables
- SMPTE 310M/292M/259M/297M/424M Support
What our Experts Think
-
Professional Fiber‑Optic I/O Module – Enables high‑quality transmit and receive of audio/video signals over fiber, expanding connectivity for compatible Marshall MD series rack monitors.
-
Broad SMPTE Support – Works with multiple industry standards (310M, 292M, 259M, 297M, 424M), ensuring compatibility across SD, HD, and 3G environments.
-
Wide Data Bandwidth – Handles data rates from ~19.4 Mbps up to 3 Gbps for robust performance with minimal jitter.
-
Fiber Optic Advantage – Long‑distance transmission with low signal loss and low return losses (< 10 dB @ 3 GHz), ideal for broadcast and live‑production workflows.
-
Modular & Flexible – Designed as a plug‑in TeleCube module, it easily integrates into modular rack monitor systems for scalable setups.
-
Expert‑Recommended – A valuable upgrade for professional AV installations needing reliable, high‑speed optical signal I/O.
Q&A
Q1: What is the purpose of this module?
A1: Serves as a fiber optic input/output base module for high-speed video and data transmission.
Q2: What applications is it suitable for?
A2: Ideal for broadcast, live production, and studio environments requiring reliable fiber connectivity.
Q3: Is it compatible with other systems?
A3: Yes, designed for Marshall TeleCube modular systems.
Q4: Does it maintain signal quality?
A4: Yes, ensures high-quality, low-latency video and data transmission.
Q5: Is installation straightforward?
A5: Yes, allows quick and secure insertion into compatible TeleCube chassis.
Maintenance Tips
-
Keep Clean: Dust the module and connectors regularly with a soft, dry cloth to prevent signal loss.
-
Inspect Connections: Ensure fiber optic cables are properly seated to maintain high-quality transmission.
-
Avoid Moisture: Protect module from liquids and high humidity to prevent damage.
-
Check for Damage: Inspect cables and ports for bends, scratches, or breaks.
-
Handle Safely: Avoid touching exposed fibers to prevent contamination and maintain signal integrity.
