Vollrath FC-4DH-03120-T Steam Tables & Food Wells - FC-4DH-03120-T

Regular price ~~$2,601.35~~ $2,393.99 Sale

Vollrath FC-4DH-03120-T Steam Tables & Food Wells - FC-4DH-03120-T

120 V | Thermostatic controls | 1000 W per well | Made in USA

Keep entrées and sides hot without the hassle of water management. The Vollrath FC-4DH-03120-T is a waterless, three-well drop-in that installs flush in virtually any counter, delivers precise thermostatic heat, and plugs into a standard 120-volt NEMA 5-50 outlet—no hard-wiring required.

Features

Waterless design – no drains, heaters or refills to manage.
(3) full-size wells accept pans up to 6″ (15.2 cm) deep; adapter bars recommended for fractional pans.
Individual thermostatic controls with power indicator lights for each well.
Open-element heating with moisture-resistant stainless steel shroud for rapid response and easy clean-up.
Zero-clearance top-mount installation; fits counters up to 3″ (7.6 cm) thick with included gasket & clips.
Remote stainless steel control panel on a 4′ (122 cm) tether lets you mount controls exactly where you need them.
Fully insulated on all non-exposed sides—including between wells—for cooler counter surfaces and energy efficiency.
6′ (1.8 m) cord & NEMA 5-50P plug—just drop in, tighten the clips, and power on.
NSF & cULus Listed for safe, sanitary commercial use.
Fabricated, tested and shipped from Sheboygan, Wisconsin.

Specifications

Model Number	FC-4DH-03120-T
Number / Capacity of Wells	3 wells – each accommodates one full-size 12″ × 20″ pan (up to 6″ deep)
Operation / Control	Dry (waterless); independent thermostatic control per well
Voltage / Phase	120 V / 60 Hz / 1-phase
Power / Amperage	1000 W per well (3000 W total), 25 A
Plug Type / Cord	NEMA 5-50P, 6′ cord
Overall Dimensions (W × D × H)	41½″ × 26″ × 15″
Counter Cutout	40¾″ W × 25¼″ D
Control Panel Cutout	15″ W × 3 5/16″ H
Construction	300-series stainless steel wells & flange; stainless control panel & element shroud
Country of Origin	USA

What our Experts Think

Water-free dry-heat design: Three-well drop-in hot food well uses dry heat — no water pans, steam, or drains — simplifying maintenance and reducing risk of leaks or mineral buildup.
Durable, commercial-grade build: Made from 300‑series stainless steel with high-density glass-fiber insulation for longevity and energy efficiency under heavy use.
Flexible, plug-and-play installation: Standard 120 V plug with cord and mounting clips for counters up to ~3″ thick — easy to drop into existing countertops.
Precise, independent control for each well: Each well has its own thermostatic control and power-indicator light, allowing tailored temperature settings for different dishes.
Compatible with standard foodservice pans: Accepts full-size or fractional full-size pans up to 6″ deep, ideal for entrées, sides, sauces, or buffet items.

Q&A

Q: What is the Vollrath FC-4DH-03120-T?
A: It’s a 3-well, dry-operation drop-in hot food well designed for countertop installation to hold prepared dishes at serving temperature.

Q: How does it hold food hot?
A: Uses open-element electric heating with thermostatic controls for each well. The insulated wells retain heat efficiently without the need for water, steam, or drainage.

Q: What kind of food containers does it support?
A: Compatible with standard full-size or fractional steam-table pans up to 6″ deep.

Q: What type of installation does it require?
A: Drop-in installation with zero-clearance mounting, suitable for countertops up to 3″ thick, using included mounting clips for easy placement or removal.

Q: Where is FC-4DH-03120-T best used?
A: Ideal for commercial kitchens, buffet lines, cafeterias, banquet halls, or catering setups that need reliable hot-food holding without the complexity of water-based steam tables.

Maintenance Tips

Unplug and let the unit cool completely before cleaning to avoid burns or electrical damage.
After each use, drain wells and clean with warm water and mild, non‑abrasive detergent; wipe interior and exterior surfaces, then rinse and dry thoroughly.
Descale periodically, especially if using hard water, to prevent mineral buildup and maintain heating efficiency.
Avoid abrasive tools, steel wool, harsh chemicals, or caustic cleaners, which can scratch or corrode stainless-steel surfaces.
Never operate the unit with empty wells or use pans deeper than recommended; always maintain proper water levels for safe, efficient operation.
Inspect drains, valves, seals, and electrical connections regularly to ensure proper function and prevent leaks or damage.
